Measuring a Room for Cabinets
A Guide on How to Measure for Cabinets
Measuring a room for cabinets is a critical step in determining your layout and an important step to complete before meeting with a designer. Here is a simple guide outlining the tools you'll need, step-by-step instructions on how to measure for cabinets, and some important tips to keep in mind.
Measuring a Room Provides Context
While most cabinet designers will field measure your site at some point, having rough dimensions and images available for the initial meetings will be helpful to the designer in determining the overall scope of the project.
Supplies You’ll Need
- A 16' – 25' long tape measure
- Pad of paper, preferably grid paper
- Pencil or pen, and another writing instrument in another color or a highlighter
- Having a helper is ideal, but one person (you!) needs to be consistently determining and recording the measurements
How to Measure for Cabinets Step-By-Step
- To begin, draw an outline of the room
- Measure and note the ceiling height and any existing soffits
- Measure and note all wall lengths
- Check corner "square-ness" at the floor, base and wall cabinet levels to determine if you will have any issues during installation. To check for corner square-ness:
- First, mark a point 3 feet out from the corner of one wall
- Then, mark a point 4 feet out from the corner of the adjacent wall
- Finally, measure the distance between the two marked points - if the distance is 5 feet, the corner is square (If your walls are not square, don't worry, a good installer will be able to work around any issues by using shims between the cabinets and the wall)
- Measure and note the location of obstacles along each wall, recording their height, width and depth from outside edge to outside edge (Include doors, windows and pipe chases)
- Identify and note existing plumbing, electrical and lighting center lines on all walls including:
- Plumbing
- Range hook-up
- Light switches
- Electrical outlets
- Lighting fixtures
- Phone jacks
- Heating/air vents (including locations in the floor)
- Record the height from finished floor for items like windows, outlets, and vents
- Record measurements of any freestanding furniture pieces or appliances that may stay in the room
- Have an electrician check the electrical service panel conditions to ensure it can handle any change of appliances you may be making in the kitchen
- If attic or basement walls will be affected by the renovation, make sure any plumbing or venting changes are verified by a professional
Important Tips When Measuring for Cabinets
Here are a few important tips to keep in mind when measuring a room for cabinets:
- Note window size and placement, along with trim and sill dimensions
- Note the location of ventilation and ductwork on your drawing
- Measure any items that will stay in the room and relate to your floor plan
- Make note of any electrical details, such as light switches and outlets that need to stay, or could possibly be moved
- If you will be working around existing lighting fixtures, list their dimensions to avoid any obstruction with taller items like pantry cabinets, refrigerators or crown moldings
- Once your designer has measured the space, double and triple check the measurements prior to placing your order; every component will be specially made just for you
